Technical parameter:

1. Controlled by PLC control unit

2. Running: Hydraulic transmission

3. Automatic side pouring

4. Pouring package can be cleaned automatically, and its size & initiative andle can be regulated

5. Product weight: 0.5kg-10kgs (two kinds of pouring package)

6. Pouring speed & angle can be regulated

7. Pouring methods: automatic & manual

8. One cycle time: 20-30 seconds

9. Automatic mechanical arm also applies for gravity die casting machines model PN2B360 7 PN2B03B

10. Machine dimension:1550mm x1900mmx2050mm
